Product Description

MRCOOL 5th Gen Advantage 12000 BTU 115V Ductless Mini Split Heat Pump R454B

Overview

The MRCOOL 5th Generation Advantage 12000 BTU ductless mini split heat pump provides heating and cooling for spaces up to 550 square feet. It operates on 115 volts and uses R454B refrigerant, which has a lower global warming potential and improved efficiency. The system includes a quiet indoor air handler with built-in WiFi for remote control through the SmartHVAC app. This unit is suitable for medium sized rooms such as bedrooms, offices, and sunrooms.

Benefits

  • Heats and cools areas up to 550 square feet
  • Runs on standard 115 volt home electrical circuits
  • Uses eco-friendly R454B refrigerant
  • Quiet operation for minimal noise disruption
  • WiFi enabled with smartphone app control
  • Compact and sleek indoor air handler design

Features

  • 12000 BTU heating and cooling capacity
  • 115 volt single phase power supply
  • R454B refrigerant for reduced environmental impact
  • Integrated WiFi with SmartHVAC app compatibility
  • Low noise levels with decibel rating of 32.5 for indoor unit
  • Remote control included
  • Reusable air filter
  • Requires professional installation by a licensed HVAC technician to maintain warranty
  • Extended limited lifetime warranty available with MRCOOL Care Program

Specifications

  • Brand: MRCOOL
  • Series: Advantage 5th Generation
  • Model Number: A-12-HP-C-115D-O (Condenser), A-12-HP-WMAH-115D-O (Air Handler)
  • Heating Capacity: 12000 BTU
  • Cooling Capacity: 12000 BTU
  • Voltage: 115 V
  • Phase: Single
  • Cycle Frequency: 60 Hz
  • SEER2 Rating: 21.2
  • EER2 Rating: 10.1
  • HSPF2-4 Rating: 8.7
  • HSPF2-5 Rating: 6.7
  • Max Fuse Breaker: 20 A (Condenser), 15 A (Air Handler)
  • Min Circuit Ampacity: 19 A (Condenser), 3 A (Air Handler)
  • Max Line Set Length: 82 feet
  • Liquid Line Size: 1/4 inch
  • Suction Line Size: 3/8 inch
  • Refrigerant Type: R454B
  • Refrigerant Volume: 24.34 oz
  • Compressor Motor Type: Rotary
  • Inverter: DC
  • Noise Level Indoor Unit: 32.5 dBA typical
  • Airflow CFM Speeds: 341.4, 309.0, 206.0, 176.6, 94.2
  • Mount Type: Wall
  • Filter Type: Reusable
  • Remote Control: Included
  • Dimensions Condenser (W x H x D): 30.12 x 21.85 x 11.93 inches
  • Weight Condenser: 61.29 lbs net
  • Dimensions Air Handler (W x H x D): 31.57 x 11.69 x 7.44 inches
  • Weight Air Handler: 19.4 lbs net
  • Certifications: UL Listed, CSA Listed, ETL Listed, AHRI Certified
  • Contains Chemicals and Compressed Gas
  • Proposition 65 Warning Applies
  • Warranty: 2 year parts, 1 year compressor, 1 year remote control, extended limited lifetime with enrollment
