Product Description

MRCOOL 5th Gen Advantage 36000 BTU 230V Ductless Mini Split Heat Pump R454B

Overview

The MRCOOL 5th Generation Advantage 36000 BTU Ductless Mini Split Heat Pump with 230V power supply provides efficient heating and cooling for spaces up to 1550 square feet. It uses the R454B refrigerant which improves energy efficiency and reduces greenhouse gas emissions through its low global warming potential.

This unit is suited for larger residential or commercial spaces such as open living areas, garages, bonus rooms, or small offices. The air handler operates quietly and includes built-in WiFi for control via the SmartHVAC app from any location. Installation requires a licensed HVAC professional and is typically quicker and less costly than traditional ducted systems due to its ductless design.

Benefits

  • Efficient heating and cooling suitable for areas up to 1550 square feet
  • Low environmental impact refrigerant (R454B)
  • Quiet operation with sleek air handler design
  • Remote access and scheduling through built-in WiFi and app compatibility
  • Reduced installation time and cost compared to traditional ducted systems
  • Professional installation ensures optimal performance and full warranty coverage

Features

  • 36000 BTU heating and cooling capacity
  • 230V power supply for high capacity performance
  • R454B refrigerant for energy efficient and eco-friendly operation
  • Built-in WiFi for smart remote control via app
  • Quiet operation with noise levels as low as 28 decibels on low fan speed
  • Professional grade system available at competitive pricing

Specifications

  • Brand name: MRCOOL
  • Series: Advantage 5th generation
  • Model: A-36-HP-C-230D-O (Condenser), A-36-HP-WMAH-230D-O (Air Handler)
  • Cooling and heating capacity: 36000 BTU
  • Voltage: 208-230V, single phase, 60 Hz cycle
  • SEER2 rating: 18
  • EER2 rating: 9
  • HSPF2-4 rating: 8.5
  • HSPF2-5 rating: 6.8
  • Max fuse breaker: 35A (Condenser), 15A (Air Handler)
  • Minimum circuit ampacity: 33A (Condenser), 3A (Air Handler)
  • Max line set length: 213.2 feet
  • Liquid line size: 3/8 inch
  • Suction line size: 5/8 inch
  • Compressor type: Rotary with overload protection
  • Inverter type: DC
  • Decibel rating: 60.5 dBA (Condenser), 28 to 56.5 dBA (Air Handler)
  • Air handler airflow (CFM): 882.9 / 732.8 / 518.0 / 400.2
  • Filter type: Reusable
  • Mount type: Wall (Air Handler)
  • Color: White (Air Handler)
  • Application compatibility: Works with iOS and Android via app
  • Remote control included
  • Certifications: UL, CSA, ETL, AHRI listed
  • Warranty: 2 year parts, 1 year compressor, 1 year remote control, extended limited lifetime with registration
  • Weight: 150.35 lbs net weight (Condenser), 40.34 lbs net weight (Air Handler)
  • Dimensions Condenser (W x H x D): 37.24 x 31.89 x 16.14 inches
  • Dimensions Air Handler (W x H x D): 49.57 x 14.25 x 11.1 inches
